Devcon® 10610 Aluminum Putty (F) is a high-performance, aluminum-filled epoxy putty designed for durable, non-rusting repairs to aluminum castings, machinery, and equipment. It's widely utilized in HVAC systems, automotive repairs, and general industrial maintenance.
Key Features
Aluminum-filled epoxy : Provides a metallic finish and excellent corrosion resistance.
Machinable : Once cured, it can be drilled, tapped, or machined.
Strong adhesion : Bonds effectively to aluminum, concrete, and various metals.
Non-sagging : Can be applied up to 6 mm thick on vertical surfaces without sagging.
Chemical resistance : Resistant to a range of chemicals, including oil, gasoline, water, and many solvents.
Technical Specifications | |
| Property | Value |
| Color | Aluminum gray |
| Mix Ratio (Resin:Hardener) | 9:1 by weight; 4:1 by volume |
| Working Time | ~30 minutes @ 24°C |
| Functional Cure | 16 hours @ 24°C |
| Hardness | 85 Shore D |
| Tensile Strength | 2,600 psi (17.9 MPa) |
| Compressive Strength | 8,400 psi (57.9 MPa) |
| Temperature Resistance | Up to 121°C (250°F) dry; 49°C (120°F) wet |
| Dielectric Strength | 100 V/mil |
Applications
Repairing aluminum castings : Ideal for patching voids or defects in castings.
Rebuilding machinery : Restores worn parts to their original dimensions.
HVAC equipment maintenance : Suitable for repairing components exposed to temperature variations.
Creating jigs and fixtures : Useful in tool and die applications.
Handling & Safety
- Surface Preparation : Clean surfaces thoroughly with a suitable cleaner (e.g., Devcon® Cleaner Blend 300) to remove oil, grease, and dirt. Grit blasting or grinding is recommended to enhance adhesion.
- Mixing : Combine resin and hardener according to the specified ratio until a uniform, streak-free consistency is achieved.
- Application : Apply the mixed putty to the prepared surface using a putty knife or similar tool.
- Curing : Allow to cure at room temperature. Full cure is typically achieved in 16 hours.
- Storage : Store in a cool, dry place. Shelf life is approximately 3 years from the date of manufacture.
