DOWSIL™ 1-2620 Low VOC Conformal Coating is a one-part, solvent-borne silicone resin designed to protect printed circuit boards (PCBs) and electronic assemblies. This low VOC version of the original DOWSIL™ 1-2620 offers enhanced environmental compliance while maintaining excellent dielectric properties and environmental protection.
Product Overview
Composition : One-part, translucent silicone resin solution.
Cure Mechanism : Moisture-cure at room temperature; optional mild heat acceleration after solvent evaporation.
Appearance : Translucent (clear) after curing.
Viscosity : Approximately 350 mPa=s.
Tack-Free Time : Approximately 15 minutes at 25°C and 50% RH.
Durometer Hardness : Shore A 80.
Dielectric Strength : Approximately 400 V/mil.
Volume Resistivity : Approximately 1.05 × 10¹⁵ ohm=cm.
Non-Volatile Content : 31%.
Source : Dow Technical Data Sheet
Key Features
Abrasion Resistance : Cures to a resilient surface that withstands mechanical wear.
Room Temperature Cure : Eliminates the need for ovens; suitable for temperature-sensitive components.
UV Indicator : Facilitates automated inspection under UV light.
Compliance : Meets UL 94 V-0 flammability rating, UL 746E, IPC-CC-830 Amendment 1, and MIL-I-46058C Amendment 7 standards.
Application Methods : Versatile application via spray, brush, flow, dip, or automated pattern coating.
Low Odor : Solvent-borne resin coating with reduced odor for improved worker comfort.
Applications
DOWSIL™ 1-2620 Low VOC is ideal for:
Protective Coating : For rigid and flexible circuit boards, offering protection against moisture, dust, and mechanical stress.
Printed Wiring Boards (PWB) : Particularly suitable for applications requiring toughness and abrasion resistance.
High-Performance Electronics : Used in environments where electronic assemblies are exposed to harsh conditions.
Safety and Handling Overview
Handling Precautions:
* Ensure adequate ventilation during application to minimize inhalation of vapors.
* Avoid contact with skin and eyes; use appropriate personal protective equipment.
* In case of skin contact, wash thoroughly with soap and water.
* In case of eye contact, flush with water and seek medical attention if irritation persists.
Storage Recommendations:
* Store in a cool, dry place away from direct sunlight.
* Keep containers tightly closed when not in use.
* Shelf life is up to 36 months when stored at room temperature in unopened containers.
First Aid Measures:
* Inhalation: Move to fresh air; seek medical attention if symptoms occur.
* Skin Contact: Wash with soap and water; remove contaminated clothing.
* Eye Contact: Rinse thoroughly with water; consult a physician if irritation develops.
* Ingestion: Do not induce vomiting; seek medical attention if necessary.
